The Grand Port Maritime du Havre has selected PortAll !

The GPMH (Grand Port Maritime du Havre) has selected PortAll, our web mapping application and its module ULHYSSES for the production and automatic update of the most accurate bathymetric charts (bENC). PortAll is operated on touch-screen tables by the Hydrographic Service and as well by the Port Authority for the management of ships. In 2018, the GPMH had already selected our software PortSide to produce its port charts (ENC) in S57 standard.

Webinaire MithraSIG
Land geomatics, News

MithraSIG Webinar on the 5th of june at 2pm!

The next MithraSIG webinar starts on the 5th of June at 2pm!

Come to discover MithraSIG: an acoustic mapping software.

The MithraSIG software fully meets the needs of impact study and acoustic mapping in an outdoor environment. Produced by Geomod, MithraSIG integrates the MITHRA calculation engine of the Scientific and Technical Center for Building, as well as the 3D SIG component “Cadcorp SIS” bringing interoperability.

Once registrated, you will receive a confirmation e-mail containing information about the webinar access procedure.

Registration link: HERE .



Land geomatics, News

LB-acoustics: New distributor for MithraSIG

LB Acoustics

Geomod  is proud to announce a new partner: LB-acoustics, who will distribute our environmental acoustic software MithraSIG in Romania.

LB-acoustics was founded ten years ago in Romania. Alionte Cristian-Gabriel, Managing Director of LB Acoustics SRL:

Our company’s mission is to offer consultancy and technical support in sound, noise and vibration measurement techniques for the companies interested in improving the quality of life. Moreover, we are committed in developing new solutions with our international partners for nowadays noise pollution challenges.



This new partnership confirms the quality and the attractiveness of MithaSIG on the International market.

Pologne
Land geomatics, News

AnkomAkustik: New distributor for MithraSIG

Distributeur MithraSIGGeomod is proud to announce a new partner: AnkomAkustik, who will distribute our environmental acoustic software MithraSIG in Poland.

AnkomAkustik was founded in 2010 in Poznań. AnkomAkustik covers a wide range of acoustic challenges. Marcin Przybył , President of the Management Board :

“We design rooms acoustics for public and commercial buildings as well as smaller projects. We carry out analyses of the acoustic impact of industrial plants and linear investments, i.e. roads or railways. Our team also has knowledge and skills in the design and performance of acoustic protections, i.e. housing or acoustic silencers. “

This new partnership confirms the quality and the attractiveness of MithaSIG on the International market.

data
Geomod blog, Land

MithraSIG: How to simplify the creation of terrain from grids

Reminder

The French Geographic Institute (IGN) and more and more data providers are delivering the ground in the form of ASC grids with small pixel size (1 m or even 10 cm).

MithraSIG creates a ground as points and contour lines. The integration function converts grids (“ASC” format for example) into points. The major problem lies in the fact that the number of points produced is huge (several millions) and not very relevant in the zones of almost flat landscape where the ground has no effect on the acoustic propagation (outside the ground effect).

grids

Example: we have four ASC grids of 1000 x 1000 pixels with a pixel size of 1 m, that corresponds to four million points on 4 km².

Operating principle

The new MithraSIG function reduces the number of points from these grids by considering a maximum tolerated difference chosen by the user between the initial and produced data.

An altitude comparison is done for each point between a complete data triangulation and an approximate triangulation while remaining within the tolerance. The result thus obtained represents the feature points of the ground: ridges, peaks, valleys, slope breaks, and mounds. These are the points that we seek to identify and to model in acoustics.

Ground selection



Ground

Figure 1 Ground creation with a tolerance of 20 cm



Consequence on the ground

Consequnce on the ground

A tolerance of 20 cm divide the number of points by 250. The average deviation (with the original data) is 10 cm.

With a tolerance of 1 m, there is an average loss of precision of 50 cm and a theoretical maximum loss of 1 m. We reduce the number of points by more than 2600.

Consequence on simulation

Consequence on simulation

Comparisons are made with all the same calculation parameters. The average difference is made in absolute value in order to avoid that errors compensate each other.

The differences of calculation with and without simplification of the ground are weak. However, locally, one can find important differences: some rays appear as diffracted in one case and not on the other. This is especially true in the NMPB08 method where the height of the source is low (5 cm).

Detail



Conclusion

Simplification of the terrain depends on the wanted precision of the simulations: this precision varies between a city cartography and an environmental impact study.

We calculate from ray tracing: details below the wavelength (less than 10 cm) do not improve the precision of the simulations. We advise to always simplify the data (with a tolerance of 10 or 20 cm) which significantly reduces the number of points and computation time without altering the results.
